PerTronix Performance Products Flame-Thrower II High Vibration Ignition Coil
Flame-Thrower II coils feature a very low resistance which make them the ideal coil for Ignitor II ignition systems as well as many other high performance ignitions. Low resistance and improved turns ratio help to produce up to 45,000 volts. This higher voltage enables you to run larger spark plug gaps for added power and better fuel economy. These epoxy filled coils provide superior winding support for high vibration environments in circle track, off-road vehicles, and boats. Designed for electronic and/or CD ignitions.
• 45,000 Volts
• Black "Stock Look"
• Epoxy Filled
• For use with electronic and/or CD ignition systems.
• Low 0.6 Ohm primary resistance
• Legal in all 50 states and Canada. (C.A.R.B. E.O #D-57-21).
• Limited 90 Day Warranty.
Part Type: Ignition Coil
Application: Universal
Coil Style: Canister
Maximum Voltage: 45,000
Primary Resistance: 0.6 ohms
Secondary Resistance: 9.0K ohms
Coil Internal Construction: Epoxy-filled
Coil Shape: Round
Turns Ratio: 100:1
Inductance: 6.0 mH
Peak Current: 7.2 Amps
Spark Duration: 1.5 mS
Coil Wire Attachment: Female/Socket
Mounting Bracket Included: No
Coil Wire Included: No
Ballast Resistor Included: No
Coil Color: Black
Coil Diameter: 2.150"
Coil Height: 6.000"
Manufacturer: Pertronix Performance Products
Manufacturer's Part Number: 45111
UPC: 694342007614
Weight: 1.50 lbs.
Warranty: 90 Day Warranty
Quantity: Sold as Each
|
