Moroso "Stroker" Kicked-Out Sump Pan
Constructed with a "stroker notch" core giving room for larger strokes (up to 4.125" SB) without modification to pan rail. Kicked-out sump moves oil away from rotating assembly, increases capacity and provides additional ground clearance. Use universal dipstick (25970).
Part Type: Oil Pan
Application: Chevrolet Small Block (except '62-'67 Chevy II and V8 Monza/Vega)
Oil Pan Style: Street/Strip
Oil Pan Capacity: 7 Quarts
Oil Pan Depth: 8.250"
Oil Pan Sump Depth: 8.250"
Sump Location: Rear
Sump Style: Wet
Kicked Out Sump: Yes
Rear Main Seal Style: 2-Piece
Stroker Clearanced: Yes
Maximum Stroke with Steel Rod: 4.125"
Dipstick Provision: Yes
Dipstick Location: Driver Side
Dipstick Included: No
Baffled: Yes
Trap Door Baffle: Yes
Crank Scraper Included: Yes
Windage Tray Included: Yes
Sump Tray Included: No
Oil Level Sight Plug: No
Oil Temp Fitting: No
Pickup Included: No
Recommended Pickup for M55 Style Pump: MOR24170
Recommended Pickup for M55A Style Pump: MOR24350
Recommended Pickup for M155HV Style Pump: MOR24360
Oil Pump Included: No
Oil Pump Driveshaft Included: No
Drain Plug Included: Yes
Inspection Fitting: No
Gaskets Included: No
Hardware Included: No
Oil Pan Material: Steel
Oil Pan Finish: Clear Zinc
Manufacturer: Moroso
Manufacturer's Part Number: 20196
UPC: 084663201967
Weight: 14.60 lbs.
Warranty: http://moroso.com/warranties
Quantity: Sold as Each
|
