Howards Cams Hydraulic Roller Camshaft
All Howards™ cams use the highest-grade quality cores available. Computer designed with knowledge of over 65 years of performance and racing camshaft manufacturing. Howards™ cams are manufactured on dedicated high precision cam grinding machines. Rockwell checked and Parkerized to ensure the highest quality control standards available anywhere. Packaged and shipped in a unique hard, high impact plastic reusable case. This ensures that the high quality camshaft that went into the case comes out in the same condition, when delivered, as when it was packed.
Manufactured on Dedicated High Precision Machines
Held to Strict Tolerances
High grade quality cores
Rockwell Tested Ensuring the Highest Quality
Part Type: Camshaft
Application: Chrysler 5.2L 5.9L Magnum 1992-2002
Ignition Firing Order: OE (1-8-4-3-6-5-7-2)
Cam Style: Hydraulic Roller
Basic RPM Range: 1200-5700
Manufacturers Description: Mild idle, street performance, big low end torque. Should have 9.0:1+ CR, 1800+ stall.
Intake Duration @ .050": 221
Exhaust Duration @ .050": 225
Advertised Intake Duration (@ .006"): 274
Advertised Exhaust Duration (@ .006"): 278
Intake Valve Lift with OE Rocker Ratio (1.60): .507"
Exhaust Valve Lift with OE Rocker Ratio (1.60): .533"
Intake Lobe Lift: .316"
Exhaust Lobe Lift: .333"
Intake Valve Lift with 1.65 Rocker Ratio: .523"
Intake Valve Lift with 1.70 Rocker Ratio: .539"
Intake Valve Lift with 1.72 Rocker Ratio: .545”
Exhaust Valve Lift with 1.65 Rocker Ratio: .550"
Exhaust Valve Lift with 1.70 Rocker Ratio: .566"
Exhaust Valve Lift with 1.72 Rocker Ratio: .573"
Lobe Separation Angle: 112 Degrees
Intake Centerline: 108 Degrees
Lifters Included: No
Small Base Circle: No
Cam Gear Attachment: Single-Bolt
Valve Adjustment: Zero Lash Plus ˝ Turn
Manufacturer: Howards Cams & Racing Components
Manufacturer's Part Number: 771915-12
Weight: 10.0 lbs.
Warranty: Race Application, No warranty expressed or implied
Quantity: Sold as Each
Note: Stock (O.E) valve springs cannot be used.
|
