Howards Cams Hydraulic Flat Tappet Cam & Lifter Set
Howards Cams most popular computer designed performance hydraulic flat tappet cams are available as cam and lifter sets. These sets offer sizable torque, horsepower, and rpm increases at an affordable price. Each set includes a hydraulic flat tappet performance cam and a set of premium hydraulic lifters.
Manufactured on Dedicated High Precision Machines
Held to Strict Tolerances
High grade quality cores
Rockwell Tested & Parkerized Ensuring the Highest Quality
Includes Matching Premium Lifters
Part Type: Camshaft & Lifter Set
Application: Ford Small Block V8 221-255-260-289-302, '63-'95 (except 302 H.O.)
Ignition Firing Order: OE (1-5-4-2-6-3-7-8)
Cam Style: Hydraulic Flat Tappet
Basic RPM Range: 1700-5700
Manufacturers Description: Good low & mid-range horsepower. Needs 4 barrel & headers.
Intake Duration @ .050": 220
Exhaust Duration @ .050": 220
Advertised Intake Duration (@ .006"): 267
Advertised Exhaust Duration (@ .006"): 267
Intake Valve Lift with OE Rocker Ratio (1.60): .543"
Exhaust Valve Lift with OE Rocker Ratio (1.60): .543"
Intake Lobe Lift: .339"
Exhaust Lobe Lift: .339"
Intake Valve Lift with 1.65 Rocker Ratio: .560"
Intake Valve Lift with 1.70 Rocker Ratio: .577"
Intake Valve Lift with 1.72 Rocker Ratio: .584"
Exhaust Valve Lift with 1.65 Rocker Ratio: .560"
Exhaust Valve Lift with 1.70 Rocker Ratio: .577"
Exhaust Valve Lift with 1.72 Rocker Ratio: .584"
Lobe Separation Angle: 108 Degrees
Intake Centerline: 104 Degrees
Lifters Included: Yes, 91211, Performance Hydraulic Flat Tappet
Small Base Circle: No
Cam Gear Attachment: 3-Bolt
Valve Adjustment: Zero Lash Plus 1/2 Turn
Manufacturer: Howards Cams & Racing Components
Manufacturer's Part Number: CL210991-08
Weight: 10.0 lbs.
Warranty: Race Application, No warranty expressed or implied
Quantity: Sold as Each
Note: Oil with ZDDP or ZDDP Additive Required
Note: Stock (O.E.) valve springs cannot be used.
Note: Lobe designed to take maximum advantage of .875" lifter dia.
|
