Howards Cams Hydraulic Flat Tappet Camshaft & Lifter Kit
All Howards cams use the highest-grade quality cores available. Computer designed with knowledge of over 65 years of performance and racing camshaft manufacturing. Howards cams are manufactured on dedicated high precision cam grinding machines. Rockwell checked and Parkerized to ensure the highest quality control standards available anywhere. Packaged and shipped in a unique hard, high impact plastic reusable case. This ensures that the high quality camshaft that went into the case comes out in the same condition, when delivered, as when it was packed.
Manufactured on Dedicated High Precision Machines
Held to Strict Tolerances
High grade quality cores
Rockwell Tested & Parkerized Ensuring the Highest Quality
Includes Matching Premium Lifters
Part Type: Camshaft & Lifter Set
Application: Chrysler Small Block LA V8 273-340-360 '64-'03, 318 '67-'91
Ignition Firing Order: OE (1-8-4-3-6-5-7-2)
Cam Style: Hydraulic Flat Tappet
Basic RPM Range: 1500-5200
Manufacturers Description: Great cam for use in Performance Street cars & PUs.
Intake Duration @ .050": 215
Exhaust Duration @ .050": 215
Advertised Intake Duration (@ .006"): 269
Advertised Exhaust Duration (@ .006"): 269
Intake Valve Lift with OE Rocker Ratio (1.50): .455"
Exhaust Valve Lift with OE Rocker Ratio (1.50): .455"
Intake Lobe Lift: .303"
Exhaust Lobe Lift: .303"
Intake Valve Lift with 1.55 Rocker Ratio: .470"
Intake Valve Lift with 1.60 Rocker Ratio: .485"
Intake Valve Lift with 1.65 Rocker Ratio: .500"
Exhaust Valve Lift with 1.55 Rocker Ratio: .470"
Exhaust Valve Lift with 1.60 Rocker Ratio: .485"
Exhaust Valve Lift with 1.65 Rocker Ratio: .500"
Lobe Separation Angle: 112 Degrees
Intake Centerline: 108 Degrees
Lifters Included: Yes, 91711, Performance Hydraulic Flat Tappet
Small Base Circle: No
Cam Gear Attachment: Single-Bolt
Valve Adjustment: Zero Lash Plus 1/2 Turn
Manufacturer: Howards Cams & Racing Components
Manufacturer's Part Number: CL710931-12
Weight: 10.0 lbs.
Warranty: Race Application, No warranty expressed or implied
Quantity: Sold as Each
Note: Oil with ZDDP or ZDDP Additive Required
|
