Howards Cams Hydraulic Flat Tappet Camshaft
All Howards™ cams use the highest-grade quality cores available. Computer designed with knowledge of over 65 years of performance and racing camshaft manufacturing. Howards™ cams are manufactured on dedicated high precision cam grinding machines. Rockwell checked and Parkerized to ensure the highest quality control standards available anywhere. Packaged and shipped in a unique hard, high impact plastic reusable case. This ensures that the high quality camshaft that went into the case comes out in the same condition, when delivered, as when it was packed.
Manufactured on Dedicated High Precision Machines
Held to Strict Tolerances
High grade quality cores
Rockwell Tested & Parkerized Ensuring the Highest Quality
Hard protective packaging
Part Type: Camshaft
Application: Chrysler Small Block LA V8 273-340-360 '64-'03, 318 '67-'91
Ignition Firing Order: OE (1-8-4-3-6-5-7-2)
Cam Style: Hydraulic Flat Tappet
Basic RPM Range: 1500-4800
Manufacturers Description: Strong mid-range torque. Needs 4 barrel & good flowing exhaust. 1800+ stall.
Intake Duration @ .050": 213
Exhaust Duration @ .050": 213
Advertised Intake Duration (@ .006"): 267
Advertised Exhaust Duration (@ .006"): 267
Intake Valve Lift with OE Rocker Ratio (1.50): .450"
Exhaust Valve Lift with OE Rocker Ratio (1.50): .450"
Intake Lobe Lift: .300"
Exhaust Lobe Lift: .300"
Intake Valve Lift with 1.55 Rocker Ratio: .465"
Intake Valve Lift with 1.60 Rocker Ratio: .480"
Intake Valve Lift with 1.65 Rocker Ratio: .495"
Exhaust Valve Lift with 1.55 Rocker Ratio: .465"
Exhaust Valve Lift with 1.60 Rocker Ratio: .480"
Exhaust Valve Lift with 1.65 Rocker Ratio: .495"
Lobe Separation Angle: 110 Degrees
Intake Centerline: 106 Degrees
Includes Lifters: No
Small Base Circle: No
Cam Gear Attachment: Single-Bolt
Valve Adjustment: Zero Lash Plus ˝ Turn
Manufacturer: Howards Cams & Racing Components
Manufacturer's Part Number: 711021-10
Weight: 10.0 lbs.
Warranty: Race Application, No warranty expressed or implied
Quantity: Sold as Each
Note: Oil with ZDDP or ZDDP Additive Required
|
