Fuel Pumps
The world famous Red®, Blue® and Black® fuel pumps are the most recognized performance pumps of all times. They have been powering racing legends and street enthusiasts alike since the early 70's. Their time proven rotor/vane design is known to get the job done in an affordable package.
Features:
- Tumble polished billet look
- Lower housing casting designed for enhanced fuel flow
- Improved design for street/strip applications
- Distinctive “Black” logo
- Compatible with alcohol or methanol fuels
- Not designed for use on aircraft of any type.
- Flows 140 GPH (free flow)
- Flows 120 GPH at 9 psi
- Maximum pressure is 14 psi
- 3/8” NPT inlet and outlet ports
- Fuel pressure regulator is required (recommend Holley P/N 12-704 for gasoline & P/N 12-707 for alcohol)
- Motor draws only 4 amps current
- Relay kit P/N 12-753 & 7 1/2 amp fuse recommended
- Provides constant fuel flow with no pulsation
- Has externally accessible pressure relief valve (max 14 psi)
- Rotor/vane pump design is more tolerant of contaminated fuels
- Weighs only 3 lbs
- Includes mounting bracket
- Repair kits are readily available
- Can be serviced from the pump end
- Use of safety shut-off switch, P/N 12-810, strongly recommended
- Not designed or recommended for use with fuel injection systems
Part Type: Carburetors
UPC: 090127484302
Fuel Pump Type: Electric External
Gph A: 120
Gph A PSI: 9
E85 Compatible: No
Maximum Pressure: 14 PSI
Diesel Compatible: No
Methanol Compatible: Yes
Gasoline Compatible: Yes
Flow Rate: 140 gph/530 lph
Inlet Attachment: Female Threads
Outlet Attachment: Female Threads
Inlet/Outlet Quantity: 1
Fuel Pump Inlet/Outlet Size: 3/8" NPT
Remanufactured: No
Pulley Included: No
Gasket Included: No
Mounting Bracket Included: Yes
Note: This pump flows 120 gph at 9 psi.
Quantity Sold as: Individually
|
