GRP Aluminum Connecting Rods
CNC machined from a special aluminum alloy plate that provides a combination of high strength, high fracture toughness and good resistance to fatigue crack propagation at high stress levels. Their manufacturing process takes advantage of the CNC's capabililty in that the rod is built around the actual center distance. These rods are honed to size, holding an honest +/- .0002 tolerance, and from that finished bore the final center to center distance is cut holding a +/- .0002 tolerance in the center to center distance of the rod. The rods are then polished with a high energy finishing machine to remove stress risers and to give the rod a durable polished finish.
1000 Series - Lightweight small block rod. Designed around 2.100" (Chev SB LJ) crank journal applications. 3/8" ARP rod bolts.
Part Type: Connecting Rods
Application: Chevrolet Small Block
Connecting Rod Beam Style: I-Beam
Material: Billet Aluminum
Connecting Rod Finish: Polished
Connecting Rod Length Center to Center: 6.000"
Connecting Rod Journal: 2.100"
Housing Bore: 2.225"
Pin Bore Diameter:
Big End Width:
Pin End Width:
Pin Fit: Yes
Typical Rod Weight:
Weight Matched Set:
Cap Alignment: 360° Radial Serrations
Fastener Type: Cap Screw
Fasteners: 3/8” ARP
Fastener Head Style: 12-Point
Fastener Yield Strength:
Recommended Bearings: CB663HND, KEBCR807HPND
Manufacturer: GRP Connecting Rods
Manufacturer's Part Number: 1000-6000
Connecting Rod Set Weight: 9.0 lbs.
Quantity: Sold in Sets of 8
