Elgin Pushrods, 5/16" Dia., .110" Wall, 210° Tip, 6.850" Length

Elgin .110" Thick-Wall 210 Degree Tip Pushrods
.110" wall thickness offers unsurpassed strength and durability. Greater column strength and increased stiffness. Manufactured from 4130 aircraft quality seamless chrome moly material. Through hardened and black oxide coated for superior strength and durability. Center-less ground and hard turned .1565" x 210 deg. radius ends.

Part Type: Pushrods
Material: 4130 Chrome Moly
Tube Finish: Black Oxide
One-Piece Pushrod: Yes
Tube Diameter: 5/16"
Pushrod Wall Thickness: .110"
Intake Overall Length: 6.850"
Exhaust Overall Length: 6.850"
Top Tip Style: Ball
Top Tip Diameter: 5/16"
Bottom Tip Style: Ball
Bottom Tip Diameter: 5/16"
Tip Attachment: Swedged
Tapered: No
Oiling: Yes
Heat-Treated: Yes
For use with Guide-plates: Yes
Manufacturer: Elgin
Manufacturer's Part Number: PR-15685
Packaged Weight: NA
Warranty: No warranty expressed or implied.
Quantity: Sold Individually
