Chevrolet Small Block Dish
Cylinder Bore: 4.000"
Compression Distance: 1.265"
Stroke/Rod: 3.750" w/ 5.700" Rod
Dome Volume: 6cc
Comp Ratio 3.750" Stroke w/64cc Heads: 9.7

SALE PRICE LIMITED TO STOCK ON HAND

NO RETURNS ALLOWED

Chevrolet Small Block Flat Top
Cylinder Bore: 4.060"
Compression Distance: 1.433"
Stroke/Rod: 3.750" w/ 5.700" Rod
Dome Volume: -6.4cc
Comp Ratio 3.750" Stroke w/64cc Heads: 11.0

Icon Pistons, Aluminum Pistons, Chev SB 383, Solid Dome, 4.030" Bore, 3.750" Stroke, 5.700" Rod

Chevrolet Small Block Solid Dome
Cylinder Bore: 4.030"
Compression Distance: 1.433"
Stroke/Rod: 3.750" w/ 5.700" Rod
Dome Volume: 1cc
Comp Ratio 3.750" Stroke w/64cc Heads: 12.0

Chevrolet Small Block Solid Dome
Cylinder Bore: 4.060"
Compression Distance: 1.433"
Stroke/Rod: 3.750" w/ 5.700" Rod
Dome Volume: 1cc
Comp Ratio 3.750" Stroke w/64cc Heads: 12.0

Icon FHR Series (Forged Head Relief) Forged Pistons,Flat Top, 4.060" Bore, 3.750" Stroke, 6.000" Rod, Set of 8

Chev SB 383
Bore: 4.060
Stroke: 3.750
Rod: 6.000
4VR Flat Top 11.0:1 (w/64cc)
With 1/16, 1/16, 3/16 Ring Grooves

SALE PRICE LIMITED TO STOCK ON HAND

NO RETURNS ALLOWED

Icon FHR Series (Forged Head Relief) Forged Pistons,Dish Top, 4.165" Bore, 3.750" Stroke, 5.700" Rod, Set of 8

Chev SB 400
Bore: 4.165
Stroke: 3.750
Rod: 5.700
Dish 9.7:1 (w/64cc)
With 5/64, 5/64, 3/16 Ring Grooves

SALE PRICE LIMITED TO STOCK ON HAND

NO RETURNS ALLOWED

Icon FHR Series (Forged Head Relief) Forged Pistons,Flat Top, 4.185" Bore, 3.750" Stroke, 6.000" Rod, Set of 8

Chev SB 400
Bore: 4.185
Stroke: 3.750
Rod: 6.000
Flat Top 11.9:1 (w/64cc)
With 1/16, 1/16, 3/16 Ring Grooves

Chevrolet SB Inverted Dome
Cylinder Bore: 4.155"
Compression Distance: 1.000"
Stroke/Rod: 4.000" w/ 6.000" Rod
Dome Shape: -20cc
Comp. Ratio: 4.000" Stroke w/ 64cc Heads: 10.6
Piston Rings Included: Yes, Low Drag File-Fit Rings

SALE PRICE LIMITED TO STOCK ON HAND

NO RETURNS ALLOWED

Icon FHR Series (Forged Head Relief) Forged Pistons,Dish Top, 4.155" Bore, 3.750" Stroke, 5.700" Rod, Set of 8

Chev SB 400
Bore: 4.155
Stroke: 3.750
Rod: 5.700
Dish 9.7:1 (w/64cc)
With 5/64, 5/64, 3/16 Ring Grooves

SALE PRICE LIMITED TO STOCK ON HAND

NO RETURNS ALLOWED

Chev SB Flat Top
Cylinder Bore: 4.030"
Compression Distance: 1.125"
Stroke/Rod: 3.480" w/ 6.000" Rod
Stroke/Rod: 3.500" w/ 6.000" Rod
Dome Volume: -5cc
Comp Ratio: 3.480" Stroke w/64cc Heads: 10.3
Comp Ratio: 3.500" Stroke w/64cc Heads: 10.4

HUGE STOCK CLEARANCE

                   IN STOCK

Chev SB Dome
Cylinder Bore: 4.030"
Compression Distance: 1.250"
Stroke/Rod : 3.480" w/ 6.000" Rod (355ci)
Stroke/Rod : 3.500" w/ 6.000" Rod (357ci)
Dome Volume: 13cc
Comp Ratio: 3.480" Stroke w/64cc Heads: 13.1
Comp Ratio: 3.500" Stroke w/64cc Heads: 13.2

HUGE STOCK CLEARANCE

                 IN STOCK

Chev SB Inverted Dome (Dish)
Cylinder Bore: 4.030"
Compression Distance: 1.425"
Stroke/Rod: 3.750" with 5.700" Rod (383ci)
Dome Volume: -28cc
Comp Ratio: 3.750" Stroke w/64cc Heads: 8.8

HUGE STOCK CLEARANCE

                   IN STOCK
