Comp Cams LS1/2/6 Beehive Valve Springs
Designed for hydraulic roller cams with .600” maximum lift. Originally designed for LS1, LS2, and LS6 engines. Will work in 5.7L Chrysler Hemi as well as many other applications. Sets of 16.
Part Type: Valve Springs
Style: Beehive Valve Springs
Type: Beehive
Damper Included: No
Top Outer Spring Out Side Diameter (O.D.): 1.055"
Top Outer Spring In Side Diameter (I.D.): .650"
Bottom Outer Spring Out Side Diameter (O.D.): 1.290"
Bottom Outer Spring In Side Diameter (I.D.): .885"
Inner Spring Out Side Diameter (O.D.): NA
Inner Spring In Side Diameter (I.D.): NA
Seat Pressure: 105 @ 1.800"
Open Pressure: 293 @ 1.200"
Valve Spring Rate: 313
Maximum Suggested Lift: .600"
Coil Bind: 1.100"
Electro Polished: No
Nitrided: No
Suggested Steel Retainers: 787-16
Suggested Titanium Retainers: CCA788-16
Suggested Seat Cups: NA
Suggested Locators: NA
Manufacturer: Comp Cams
Manufacturer's Part Number: 26915-16
Packaged Weight: 3.0 lbs.
Warranty: 1 year limited warranty from the date of purchase by the original purchaser.
Quantity: Sold in Sets of 16 |
